MULTI 55
Vertical centrifugal multistage pump for water supply.
Pumping of clean water for domestic, industrial, agricultural and gardening purposes. Suitable for applications like water transfer, sprinkler or drip irrigation, domestic booster or booster sets. Silent.
Features
Equipment
- Counter flanges: Included
Manufacturing features
- Discharge connection type: Thread
- Discharge diameter: 1 1/4″
- Motor cooling: Fan
- Suction connection type: Thread
- Suction diameter: 1 1/2″
- Tightness by: Mechanical seal
Limitations
- Water temperature (ºC): Max: 40
Electrical features
- Electrical isolation: F Class
- Motor type: Asynchronous
- Protection rating: IPX5
- Reset: Automatic
- Service factor: S1
Materials
- Diffuser/s: Technopolymer
- Discharge body: Cast iron
- Impeller/s: Stainless steel AISI 304
- Mechanical seal: Aluminium-Graphite
- Motor casing: Aluminium
- O-rings: NBR/EPDM
- Pump body: Stainless steel AISI 304
- Pump shaft: Stainless steel AISI 420
- Suction body: Cast iron
